Product Overview
The ASOL 1160110-3S 11.1V 8000mAh Lithium Polymer Battery Pack is designed for applications requiring high energy density, compact size, and reliable power output.
Featuring a 3S LiPo configuration, this battery pack provides stable voltage performance and high capacity in a lightweight design. It is suitable for professional portable equipment and industrial applications where space efficiency and battery performance are important.
ASOL supports OEM battery customization including voltage configuration, capacity adjustment, connector selection, cable design, and battery pack structure customization.
Technical Specifications
| Parameter | Value |
|---|---|
| Battery Type | Lithium Polymer Battery Pack |
| Model | ASOL1160110-3S |
| Configuration | 3S LiPo Battery Pack |
| Nominal Voltage | 11.1V |
| Rated Capacity | 8000mAh |
| Rated Energy | 88.8Wh |
| Charge Limited Voltage | 12.6V |
| Charge Current | N/A |
| Discharge Current | N/A |
| Battery Dimension | T11.6 × W110 × L110mm |
| Charging Temperature | 0-45°C |
| Discharge Temperature | -10-60°C |
| Manufacturer | ASOLENERGY TECHNOLOGY |
Note: For product design and battery selection, please confirm the final drawing, connector requirement and project specification before mass production.
Key Features
High-capacity 3S lithium polymer battery pack
3S LiPo battery pack architecture for compatible 11.1V professional equipment.
High-capacity pack design with 88.8Wh rated energy for extended runtime.
Pack dimensions of T11.6 × W110 × L110mm for space-conscious equipment integration.
Designed for professional portable equipment that requires stable output performance.
Suitable for UAV systems, robotics, camera equipment, medical devices and industrial terminals.
Connector, wire, label, PCM/BMS and pack structure requirements can be reviewed.
Applications
Where the 1160110-3S is used
Industrial drones, aerial drones and inspection UAV systems.
Service robots, AGV robots and inspection robots.
Camera monitors, wireless video transmitters and filmmaking accessories.
Portable displays, handheld terminals and outdoor monitoring devices.
Portable medical instruments, monitoring devices and mobile diagnostic equipment.
Industrial control terminals, inspection instruments and data collection devices.
Available Custom Configurations
ASOL 1160110-3S is supplied as a lithium polymer battery pack for OEM product integration. Project suitability should be confirmed by reviewing the device space, voltage, capacity, working current, connector, label requirements and estimated quantity.
- Pack configuration review: Confirm 3S configuration, 11.1V nominal voltage and 8000mAh capacity before production.
- Electrical matching: Confirm charge limited voltage 12.6V and project current requirements before production.
- Mechanical review: Confirm T11.6 × W110 × L110mm battery space, wire exit and connector installation.
- Labeling: Product label content, model marking and customer branding can be reviewed for qualified OEM projects.
Frequently Asked Questions
What are the key specifications of the ASOL 1160110-3S battery pack?
The ASOL 1160110-3S is an 11.1V 8000mAh lithium polymer battery pack with 88.8Wh rated energy, 12.6V charge limited voltage and T11.6 × W110 × L110mm battery dimensions.
What applications is the ASOL 1160110-3S suitable for?
It is suitable for UAV and drone systems, robotics equipment, professional camera equipment, portable electronics, medical devices and industrial equipment.
Can ASOL customize this lithium polymer battery pack?
Yes. ASOL can review voltage configuration, capacity, connector, wire length, label, PCM/BMS and battery pack structure requirements according to the device design.
What information should I provide for quotation?
Please share the target application, required quantity, working current, battery space, connector requirement, destination market and any label or packaging requirements.
